A strong, compact pump for large pools with spas, waterfalls or solar, where a dealer wants 2.7 HP in a small footprint.
Amazon $2,019.99
For pools that need a pump with built-in safety vacuum release (SVRS), such as single-drain pools where code calls for one; otherwise the IntelliFlo3 VSF is the more efficient choice.
- 4 HPRated power
- 6.9WEF
- 34% aboveAbove ENERGY STAR minimum
- 230 VVoltage
- 174 gpmMax flow
- 2 yearsWarranty
Price checked October 27, 2026. As an Amazon Associate we earn from qualifying purchases.
- Built-in safety vacuum release shuts the pump off on a drain blockage, which some codes require
- Lots of head and flow for spas, water features and large pools
- Works with Pentair’s IntelliTouch and EasyTouch systems over the included cable
- Least efficient pump in Pentair’s current line (WEF 6.9)
- 230 V only
- No Wi-Fi or app without a Pentair automation system
- Only a 2-year warranty
How it scores
The rating comes from 5 measured or published factors, each scored 0-100 against fixed reference points for its pool type. How we rank explains each one.
Specifications
| Model number | 011057 / EC-011057 |
|---|---|
| Efficiency ratings | |
| Pump type | In-ground (self-priming) |
| Motor | Variable speed |
| Rated horsepower (DOE) | 4 HP |
| Hydraulic horsepower (DOE) | 1.9 HP |
| Weighted energy factor (WEF) | 6.9 kgal/kWh |
| ENERGY STAR minimum for its size | 5.1 kgal/kWh |
| ENERGY STAR certified | Yes |
| Pump | |
| Voltage | 230 V |
| Speed range | 1,100 to 3,450 rpm |
| Maximum flow | 174 gpm |
| Pipe size | 2 in |
| Size (W × D × H) | 23.4 × 10.8 × 13.1 in |
| Controls | |
| Built-in schedule | Yes |
| Freeze protection | Yes |
| Wi-Fi | No |
| Automation compatibility | Pentair IntelliTouch, Pentair EasyTouch, Pentair SunTouch, Pentair IntelliComm |
| Warranty and models | |
| Warranty | 2 years |
| Warranty terms | Pentair lists IntelliFlo SVRS pumps at 2 years, parts and labor when professionally installed from a dealer, pool builder or service company; bought online (EC-011057) it is 2 years, parts only. Not eligible for the 3-year bundle. |
| Also sold as | Sta-Rite IntelliPro VS+SVRS (013002) |
Alternatives in this pool type
A 4 HP TriStar for large pools with heavy water-feature loads; for an ordinary pool a TriStar VS 900 or 950 uses less power.
Hayward (find a dealer)Only for large or feature-heavy pools on 2.5 to 3 in plumbing that need more flow than a 3 HP IntelliFlo3 can give.
Amazon $1,999.71Compare
