Hayward MaxFlo VS 420
#25 in In-GroundFull review
The bigger MaxFlo VS 400, for mid-size pools that need more flow in a compact body, controlled from the OmniX app.
INYOPools $1,834.99$1,834.99
2.9/5
The bigger Super Pump VS 600, for pools that need more flow than the 615 in a compact Super Pump body, controlled from the OmniX app.
- 2.2 HPRated power
- 7.7WEF
- 19% aboveAbove ENERGY STAR minimum
- 115/230 VVoltage
- 130 gpmMax flow
- 3 yearsWarranty
Check price at Amazon$1,849
Price checked October 27, 2026. As an Amazon Associate we earn from qualifying purchases.
Pros
- Compact Super Pump body fits tight pads and old Super Pump plumbing
- Runs on 115 or 230 V, so it swaps in for most old pumps
- Schedules and speeds from a phone over Bluetooth with no automation system to buy
Cons
- No keypad: schedules must be set in the OmniX app
- Doesn’t connect to Pentair or Jandy automation
- Not ENERGY STAR certified, so it may not qualify for utility rebates
The Hayward Super Pump VS 600 family
Every Hayward Super Pump VS 600 model we rank, smallest first. Ratings compare each against its own pool type.
| Model | Rated power | Rating | Price |
|---|---|---|---|
| Hayward Super Pump VS 615 | 1.6 HP | 2.8/5 | $1,699 |
| Hayward Super Pump VS 620 (this one) | 2.2 HP | 2.9/5 | $1,849 |
How it scores
The rating comes from 5 measured or published factors, each scored 0-100 against fixed reference points for its pool type. How we rank explains each one.
Specifications
| Model number | VSP26620 / W3VSP26620 |
|---|---|
| Efficiency ratings | |
| Pump type | In-ground (self-priming) |
| Motor | Variable speed |
| Rated horsepower (DOE) | 2.2 HP |
| Hydraulic horsepower (DOE) | 1.1 HP |
| Weighted energy factor (WEF) | 7.7 kgal/kWh |
| ENERGY STAR minimum for its size | 6.5 kgal/kWh |
| ENERGY STAR certified | No |
| Pump | |
| Voltage | 115/230 V |
| Speed range | 600 to 3,450 rpm |
| Maximum flow | 130 gpm |
| Pipe size | 2 in |
| Size (W × D × H) | 8.6 × 25.2 × 11 in |
| Controls | |
| Built-in schedule | Yes |
| Freeze protection | Yes |
| Wi-Fi | Optional module |
| App | Hayward OmniX |
| Automation compatibility | Hayward OmniX |
| Warranty and models | |
| Warranty | 3 years |
| Warranty terms | Sold only through pool pros: 3 years parts when sold by a Totally Hayward partner (sell sheet); the product page lists 3 years parts and 1 year labor. Exclusions and other terms at hayward.com/expert. |
| Released | 2025 |
Alternatives in this pool type
Hayward Super Pump VS 700
#26 in In-GroundFull review
A compact dual-voltage replacement for an old Hayward Super Pump on a typical in-ground pool, with keypad schedules and wide automation support.
INYOPools $1,749$1,749
Hayward Super Pump VS 615
#28 in In-GroundFull review
An app-controlled replacement for an old Hayward Super Pump on a typical in-ground pool, for owners who don’t have an automation system.
Amazon $1,699$1,699
Compare
Compare the Hayward Super Pump VS 620 with any other pool pump →
More from Hayward: every Hayward product ranked.
