Victron Phoenix 48/1600
#2 in Up to 1,500 WFull review
The largest plug-in Victron inverter for 48 V, sized for a microwave or kettle. Above this, Victron’s 48 V 120 V range is MultiPlus and Quattro inverter-chargers.
Inverters R Us $362.10$362.10
3.8/5
A good size for an efficient fridge, CPAP or entertainment loads on a 48 V system. Low idle draw means it can be left on all the time.
- 460 WContinuous
- 750 WSurge
- 120 VOutput
- 10 WIdle draw
- YesUL listed
- 5 yearsWarranty
Check price at Northern Arizona Wind & Sun$154.71
Price checked October 24, 2026. As an Amazon Associate we earn from qualifying purchases.
Pros
- Idles at about 10 W and 2 W in ECO mode
- Runs a CPAP, TV, laptop or efficient fridge with room to spare
- Can deliver 500 W for up to an hour from a cold start
- UL 458 certified, with two GFCI-protected outlets
Cons
- Continuous rating at 77 F is 460 W, a bit under the 500 VA in the name
- Phone app needs a VE.Direct Bluetooth dongle sold separately
The Victron Phoenix 48V 120V family
Every Victron Phoenix 48V 120V model we rank, smallest first. Ratings compare each against its own size.
| Model | Continuous | Rating | Price |
|---|---|---|---|
| Victron Phoenix 48/250 | 250 W | 3.7/5 | $106.26 |
| Victron Phoenix 48/375 | 375 W | 3.8/5 | - |
| Victron Phoenix 48/500 (this one) | 460 W | 3.8/5 | $154.71 |
| Victron Phoenix 48/800 | 800 W | 4.0/5 | $245.65 |
| Victron Phoenix 48/1200 | 1,200 W | 4.1/5 | $298.36 |
| Victron Phoenix 48/1600 | 1,500 W | 4.1/5 | $362.10 |
How it scores
The rating comes from 6 measured or published factors, each scored 0-100 against fixed reference points for its size. How we rank explains each one.
Specifications
| Model number | PIN481500510 |
|---|---|
| Output | |
| Type | Pure sine wave inverter |
| AC output | 120 V |
| Continuous power | 460 W |
| Surge power | 750 W for 3 s |
| DC input range | 36.8 to 62 V |
| Idle draw | 10 W (0.2 A at 48 V) |
| Power-saving draw | 2 W |
| Peak efficiency | 88% |
| Connections | |
| AC outlets | 2 |
| GFCI outlets | Yes |
| Hardwire terminal | No |
| USB ports | None |
| Transfer switch | No |
| Parallel units | No |
| Control and build | |
| Remote | Optional extra |
| App | Optional add-on |
| Display | No |
| Safety listing | LabTest certified to UL 458 (certificate LC20760-1) |
| Cooling | fan |
| Dimensions | 86 x 172 x 275 mm (3.4 x 6.8 x 10.8 in) |
| Weight | 7.7 lb |
| Warranty | 5 years |
Alternatives in this size
Victron Phoenix 48/800
#3 in Up to 1,500 WFull review
A solid small inverter for running a fridge and electronics from a 48 V bank. Victron build quality and a five-year warranty justify the price over budget brands.
Northern Arizona Wind & Sun $245.65$245.65
Victron Phoenix 48/375
#5 in Up to 1,500 WFull review
A small, frugal inverter for electronics on a 48 V system. Good for a dedicated low-power circuit next to a larger inverter.
Compare
Compare the Victron Phoenix 48/500 with any other 48V inverter →
More from Victron Energy: every Victron Energy product ranked.
