Rheem ProTerra 80 Gal
#4 in 80 GallonFull review
A strong 240 V choice with Wi-Fi, widely stocked at Home Depot. GE Profile beats it on efficiency and noise.
Home Depot $2,499$2,499
The Rheem ProTerra 80 Gal is the better heat pump water heater overall, rated 3.7 to 2.9. The Rheem ProTerra 80 Gal leads on efficiency. The A.O. Smith Voltex 120V 80 Gal wins on hot water. The Rheem ProTerra 80 Gal costs $599 less ($2,499 vs $3,098).
A.O. Smith Voltex 120V 80 Gal
#16 in 80 GallonFull review
A 120 V plug-in with a backup element and leak shut-off included. Its certified efficiency is among the lowest here, so it suits replacing a gas tank more than replacing an electric one.
Lowe's $3,098$3,098
Prices were last checked October 21, 2026 and are subject to change; the price and availability shown by the retailer at the time of purchase apply.
Which should you buy?
- Choose the Rheem ProTerra 80 Gal for efficiency (4.07 UEF vs 3.00 UEF).
- Choose the A.O. Smith Voltex 120V 80 Gal for hot water (93 gallons in the first hour vs 87 gallons in the first hour).
Scores side by side
Each factor is scored 0-100 against the same fixed reference points for every 80 gallon heat pump water heater; a clear win is highlighted. How we rank explains each one.
| Factor weight | Rheem ProTerra 80 Gal | A.O. Smith Voltex 120V 80 Gal |
|---|---|---|
| Overall rating | 3.7/5 | 2.9/5 |
| Efficiency 35% | 76 4.07 UEF | 0 3.00 UEF |
| Hot water 20% | 48 87 gallons in the first hour | 72 93 gallons in the first hour |
| Warranty 20% | 75 10-year tank, 10-year parts, 1-year labor | 75 10-year tank, 10-year parts, 1-year labor |
| Cold rooms 15% | 32 heat pump runs down to 37 °F room air | 32 heat pump runs down to 37 °F room air |
| Noise 10% | 69 45 dB(A) | 69 45 dB(A) |
Specifications
| Rheem ProTerra 80 Gal | A.O. Smith Voltex 120V 80 Gal | |
|---|---|---|
| Ratings (ENERGY STAR) | ||
| Size (nominal) | 80 gal | 80 gal |
| Tank volume (measured) | 72 gal | 82 gal |
| Uniform Energy Factor | 4.07 | 3.00 |
| First-hour rating | 87 gal | 93 gal |
| Draw pattern | High | High |
| Yearly energy use | 1,213 kWh | 1,654 kWh |
| Heat pump cut-off (low) | 37 °F | 37 °F |
| Sound level | 45 dB(A) | 45 dB(A) |
| ENERGY STAR ID | 3554247 | 2546244 |
| Installation | ||
| Power | 240 V | Plug-in 120 V |
| Circuit | 30 A, 208/240 V | Shared 15 A circuit |
| Backup element | 4,500 W | 900 W |
| Operating air range | 37 to 145 °F | 37 to 120 °F |
| Minimum room size | 700 cu ft | 450 cu ft |
| Size | 74.2 in tall, 24.3 in across | 92 in tall, 27 in across |
| Weight | 261 lb | 307 lb |
| Refrigerant | R-134a | R-513A |
| Features | ||
| Wi-Fi | Built in | Built in |
| App | EcoNet | A. O. Smith (iCOMM) |
| Demand response port (CTA-2045) | Yes | Yes |
| Leak detection | No | Yes |
| Modes | Energy Saver, Heat Pump, High Demand, Electric, Vacation | Heat Pump, Electric, Vacation |
| Warranty and models | ||
| Warranty | 10 yr tank, 10 yr parts, 1 yr labor | 10 yr tank, 10 yr parts, 1 yr labor |
| Also sold as | Friedrich PROH80 T2 FD400-30, Friedrich PROH80 T2 FD400-SO, Rheem PROPH80 T2 RH375-30, Rheem PROPH80 T2 RH400-30, Rheem PROPH80 T2 RH400-SO, Richmond 10E80-HP530, Richmond 10E80-HP5U30, Richmond 10E80-HP5US30, Ruud PROUH80 T2 RU375-30, Ruud PROUH80 T2 RU375-SO, Ruud PROUH80 T2 RU400-30, Ruud PROUH80 T2 RU400-SO | American HPV10280H009DV, Lochinvar HPV080KD, Reliance 10-80-DHPTV, State HPVX-80-DHPT |
| Released | 2024-06 | 2023-07 |
