Rheem ProTerra 40 Gal
#13 in 40–50 GallonFull review
A strong 240 V choice with Wi-Fi, widely stocked at Home Depot. GE Profile beats it on efficiency and noise.
Home Depot $2,098$2,098
The Rheem ProTerra 40 Gal is the better heat pump water heater overall, rated 3.4 to 3.1. The Rheem ProTerra 40 Gal leads on efficiency and hot water.
A.O. Smith Voltex MAX 40 Gal
#17 in 40–50 GallonFull review
A solid 240 V heater with leak protection included, sold at Lowe’s as the Signature 900 line.
Lowe's $2,098$2,098
Prices were last checked October 21, 2026 and are subject to change; the price and availability shown by the retailer at the time of purchase apply.
Which should you buy?
- Choose the Rheem ProTerra 40 Gal for efficiency (3.83 UEF vs 3.60 UEF) and hot water (60 gallons in the first hour vs 55 gallons in the first hour).
Scores side by side
Each factor is scored 0-100 against the same fixed reference points for every 40–50 gallon heat pump water heater; a clear win is highlighted. How we rank explains each one.
| Factor weight | Rheem ProTerra 40 Gal | A.O. Smith Voltex MAX 40 Gal |
|---|---|---|
| Overall rating | 3.4/5 | 3.1/5 |
| Efficiency 35% | 59 3.83 UEF | 43 3.60 UEF |
| Hot water 20% | 40 60 gallons in the first hour | 20 55 gallons in the first hour |
| Warranty 20% | 75 10-year tank, 10-year parts, 1-year labor | 75 10-year tank, 10-year parts, 1-year labor |
| Cold rooms 15% | 32 heat pump runs down to 37 °F room air | 32 heat pump runs down to 37 °F room air |
| Noise 10% | 69 45 dB(A) | 69 45 dB(A) |
Specifications
| Rheem ProTerra 40 Gal | A.O. Smith Voltex MAX 40 Gal | |
|---|---|---|
| Ratings (ENERGY STAR) | ||
| Size (nominal) | 40 gal | 40 gal |
| Tank volume (measured) | 36 gal | 36 gal |
| Uniform Energy Factor | 3.83 | 3.60 |
| First-hour rating | 60 gal | 55 gal |
| Draw pattern | Medium | Medium |
| Yearly energy use | 859 kWh | 902 kWh |
| Heat pump cut-off (low) | 37 °F | 37 °F |
| Sound level | 45 dB(A) | 45 dB(A) |
| ENERGY STAR ID | 3554180 | 3417480 |
| Installation | ||
| Power | 240 V | 240 V |
| Circuit | 30 A, 208/240 V | 30 A, 208/240 V |
| Backup element | 4,500 W | 4,500 W |
| Operating air range | 37 to 145 °F | 37 to 120 °F |
| Minimum room size | 700 cu ft | 450 cu ft |
| Size | 62.3 in tall, 20.3 in across | 66 in tall, 20 in across |
| Weight | 166 lb | 191 lb |
| Refrigerant | R-134a | R-134a |
| Features | ||
| Wi-Fi | Built in | Built in |
| App | EcoNet | A. O. Smith (iCOMM) |
| Demand response port (CTA-2045) | Yes | Yes |
| Leak detection | No | Yes |
| Modes | Energy Saver, Heat Pump, High Demand, Electric, Vacation | Hybrid, Heat Pump, Hot Water+ (3 levels), Guest, Electric, Vacation |
| Warranty and models | ||
| Warranty | 10 yr tank, 10 yr parts, 1 yr labor | 10 yr tank, 10 yr parts, 1 yr labor |
| Also sold as | Friedrich PROH40 T2 FD400-30, Friedrich PROH40 T2 FD400-SO, Rheem PROPH40 T2 RH375-30, Rheem PROPH40 T2 RH375-SO, Rheem PROPH40 T2 RH400-30, Rheem PROPH40 T2 RH400-SO, Richmond 10E40-HP530, Richmond 10E40-HP5S30, Richmond 10E40-HP5U30, Richmond 10E40-HP5US30, Ruud PROUH40 T2 RU375-30, Ruud PROUH40 T2 RU375-SO, Ruud PROUH40 T2 RU400-30, Ruud PROUH40 T2 RU400-SO | American HPA10240H045DV, Lochinvar HPPA040KD, Reliance 10-40-DHPTA, State HPAX-40-DHPT |
| Released | 2024-06 | 2024-03 |
