Ruixu RX-LFP48100-H
#3 in Server rackFull review
The heated version of Ruixu’s UL 1973 rack module, for cold garages and cabins. It costs only about $40 more than the unheated one.
Ruixu $1,099$1,099
The Ruixu RX-LFP48100-H is the better 48V solar battery overall, rated 4.6 to 4.0. The Ruixu RX-LFP48100-H leads on features.
EG4 LL-S 48V 100Ah
#10 in Server rackFull review
A 5 kWh server-rack module with a screen, for owners extending an existing EG4 LL bank. Most new buyers will find it out of stock.
Prices were last checked October 24, 2026 and are subject to change; the price and availability shown by the retailer at the time of purchase apply.
Which should you buy?
- Choose the Ruixu RX-LFP48100-H for features (inverter communication, self-heating; no app vs inverter communication; no self-heating).
Scores side by side
Each factor is scored 0-100 against the same fixed reference points for every server rack 48V solar battery; a clear win is highlighted. How we rank explains each one.
| Factor weight | Ruixu RX-LFP48100-H | EG4 LL-S 48V 100Ah |
|---|---|---|
| Overall rating | 4.6/5 | 4.0/5 |
| Value 35% | 86 $215 per rated kWh | 50 no current price (neutral score used) |
| Output 15% | 100 100 A continuous (about 5.1 kW) | 100 100 A continuous (about 5.1 kW) |
| Warranty 15% | 100 10-year warranty | 100 10-year warranty |
| Safety listing 15% | 100 UL 1973, UL 9540A listed | 100 UL 1973, UL 9540A listed |
| Cycle life 10% | 60 6,000 cycles at 90% depth, maker rating | 60 6,000 cycles at 80% depth, maker rating |
| Features 10% | 70 inverter communication, self-heating; no app | 40 inverter communication; no self-heating |
Specifications
| Ruixu RX-LFP48100-H | EG4 LL-S 48V 100Ah | |
|---|---|---|
| Capacity | ||
| Case | Server rack (19-inch) | Server rack (19-inch) |
| Nominal voltage | 51.2 V | 51.2 V |
| Capacity | 100 Ah | 100 Ah |
| Energy | 5.1 kWh | 5.1 kWh |
| Usable energy | 4.9 kWh | - |
| Chemistry | LiFePO4 | LiFePO4 |
| Cycle life | 6,000 at 90% depth | 6,000 at 80% depth |
| Power | ||
| Continuous discharge | 100 A | 100 A |
| Peak discharge | 149 A | - |
| Max charge current | 70 A | 100 A |
| Modules in parallel | Up to 32 | Up to 64 |
| Safety and communication | ||
| UL 1973 | Yes | Yes |
| UL 9540A | Yes | Yes |
| UL 9540 | No | No |
| Communication | CAN, RS485 | CAN, RS485 |
| Works with inverters | Victron, SMA, Studer, Sol-Ark, Solis, Goodwe, Deye, Growatt, LuxPower, Schneider, Voltronic, MPP | EG4, Schneider, Sol-Ark, Victron, Growatt, Megarevo, Luxpower, Deye |
| Self-heating | Yes | No |
| App | No | No |
| Build | ||
| Display | - | Yes |
| Built-in breaker | - | Yes |
| Enclosure | IP20 | IP20 |
| Dimensions | 19.0 x 18.1 x 5.3 in | 6.1 x 17.4 x 19.3 in (155 x 442 x 490 mm) |
| Weight | 103.6 lb | 99.6 lb |
| Warranty | 10 years | 10 years |
| Released | 2023-12 | 2023-09 |
