The Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 115V and the Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 230V are evenly matched, rated 3.8 and 3.8. The Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 115V costs $90 less ($1,369 vs $1,459).
The best-value quick-connect line: the same certified system as Pioneer’s Quantum Ultra, close to Della’s Optima, without the vacuum pump, for the same price or a few hundred dollars more.
Amazon $1,369The best-value quick-connect line: the same certified system as Pioneer’s Quantum Ultra, close to Della’s Optima, without the vacuum pump, for the same price or a few hundred dollars more.
Amazon $1,459Prices were last checked October 21, 2026 and are subject to change; the price and availability shown by the retailer at the time of purchase apply.
Each factor is scored 0-100 against the same fixed reference points for every 12,000 BTU DIY mini-split; a clear win is highlighted. How we rank explains each one.
| Factor weight | Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 115V | Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 230V |
|---|---|---|
| Overall rating | 3.8/5 | 3.8/5 |
| Value 35% | 78 $154 per 1,000 Btu/h of heat at 5 °F | 76 $160 per 1,000 Btu/h of heat at 5 °F |
| Cold weather 25% | 53 keeps 72% of its heat at 5 °F, heats down to -13 °F | 53 keeps 72% of its heat at 5 °F, heats down to -13 °F |
| Efficiency 20% | 66 10 HSPF2, 23 SEER2, COP 2.10 at 5 °F | 69 10 HSPF2, 24 SEER2, COP 2.10 at 5 °F |
| Warranty 15% | 64 7-year compressor, 5-year parts | 64 7-year compressor, 5-year parts |
| Noise 5% | 48 indoor unit from 30 dB(A) | 48 indoor unit from 30 dB(A) |
| Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 115V | Klimaire KIWQ-KOIQ DIY 5th Gen 12,000 BTU 230V | |
|---|---|---|
| Capacity (certified) | ||
| Size (nominal) | 12,000 BTU | 12,000 BTU |
| Cooling at 95 °F | 12,000 Btu/h | 12,000 Btu/h |
| Heating at 47 °F | 12,400 Btu/h | 12,600 Btu/h |
| Heating at 17 °F (max) | 10,000 Btu/h | 10,000 Btu/h |
| Heating at 5 °F (max) | 8,900 Btu/h | 9,100 Btu/h |
| Heat kept at 5 °F | 72% | 72% |
| Price per 1,000 Btu/h at 5 °F | $154 | $160 |
| Efficiency (certified) | ||
| HSPF2 (Region IV) | 10 | 10 |
| SEER2 | 23 | 24 |
| EER2 | 13 | 13 |
| COP at 5 °F | 2.10 | 2.10 |
| ENERGY STAR | ENERGY STAR Cold Climate | ENERGY STAR Cold Climate |
| AHRI certificate | 218067068 | 218067069 |
| Operating range | ||
| Heats down to | -13 °F | -13 °F |
| Cooling range | 5 to 131 °F | 5 to 131 °F |
| Installation | ||
| Line set connection | Quick-connect (no vacuum pump) | Quick-connect (no vacuum pump) |
| Line set | 25 ft included, up to 49 ft | 25 ft included, up to 49 ft |
| Voltage | 115 V | 230 V |
| Refrigerant | R-454B | R-454B |
| Indoor unit | KIWQ12H1-45T | KIWQ12H2-45T |
| Outdoor unit | KOIQ12H1-45T | KOIQ12H2-45T |
| Build | ||
| Indoor noise | 30–46 dB(A) | 30–46 dB(A) |
| Outdoor noise | 52 dB(A) | 52 dB(A) |
| Wi-Fi | Built in | Built in |
| Weight | indoor 23.1 lb / outdoor 58.4 lb | indoor 23.1 lb / outdoor 58.4 lb |
| Warranty | 7 yr compressor, 5 yr parts | 7 yr compressor, 5 yr parts |
| Warranty with DIY install | Yes | Yes |
| Released | 2025-10 | 2025-10 |
