The best-value quick-connect line: the same certified system as Pioneer’s Quantum Ultra, close to Della’s Optima, without the vacuum pump, for the same price or a few hundred dollars more.
Price checked October 21, 2026. As an Amazon Associate we earn from qualifying purchases.
The rating comes from 5 measured or published factors, each scored 0-100 against fixed reference points for its size. How we rank explains each one.
| Capacity (certified) | |
|---|---|
| Size (nominal) | 9,000 BTU |
| Cooling at 95 °F | 9,000 Btu/h |
| Heating at 47 °F | 10,000 Btu/h |
| Heating at 17 °F (max) | 9,100 Btu/h |
| Heating at 5 °F (max) | 7,500 Btu/h |
| Heat kept at 5 °F | 75% |
| Price per 1,000 Btu/h at 5 °F | $147 |
| Efficiency (certified) | |
| HSPF2 (Region IV) | 9.5 |
| SEER2 | 23 |
| EER2 | 13 |
| COP at 5 °F | 1.89 |
| ENERGY STAR | ENERGY STAR Cold Climate |
| AHRI certificate | 218067067 |
| Operating range | |
| Heats down to | -13 °F |
| Cooling range | 5 to 131 °F |
| Installation | |
| Line set connection | Quick-connect (no vacuum pump) |
| Line set | 25 ft included, up to 49 ft |
| Voltage | 115 V |
| Refrigerant | R-454B |
| Indoor unit | KIWQ09H1-45T |
| Outdoor unit | KOIQ09H1-45T |
| Build | |
| Indoor noise | 30–43 dB(A) |
| Outdoor noise | 50 dB(A) |
| Wi-Fi | Built in |
| Weight | indoor 20.7 lb / outdoor 53.5 lb |
| Warranty | 7 yr compressor, 5 yr parts |
| Warranty with DIY install | Yes |
| Released | 2025-10 |
The cheapest way into a certified, cold-capable heat pump, for a self-installer with a vacuum pump. Pioneer’s Quantum Ultra and the quick-connect Klimaire DIY have near-identical certified ratings.
Amazon $879.96 Della $879.96The cheapest way into a certified, cold-capable heat pump, for a self-installer with a vacuum pump. Pioneer’s Quantum Ultra and the quick-connect Klimaire DIY have near-identical certified ratings.
Amazon $899.96 Della $899.96A low price for a self-installer who owns or will rent a vacuum pump. The Klimaire DIY is the same certified system with quick-connect lines, and Della’s Optima has near-identical ratings for less.
Amazon $1,088 Pioneer Mini Split store $1,088Compare the Klimaire KIWQ-KOIQ DIY 5th Gen 9,000 BTU 115V with any other DIY mini-split →
More from Klimaire: every Klimaire product ranked.
