AIMS Power 8000W 48V Split Phase ETL
For an off-grid or backup home on 48 V that needs a listed split-phase inverter-charger with heavy surge at a lower price than Outback or Schneider.
Amazon $4,611.27 AIMS Power $4,480$4,480
The AIMS Power 8000W 48V Split Phase ETL is the better 48V inverter overall, rated 3.1 to 2.7. The AIMS Power 8000W 48V Split Phase ETL leads on safety listing, idle draw and features. The AIMS Power 10000W 48V Split Phase wins on value. The AIMS Power 10000W 48V Split Phase costs $320 less ($4,160 vs $4,480).
AIMS Power 10000W 48V Split Phase
For a big off-grid home that needs 10 kW of split phase from 48 V and doesn’t need a UL listing. If the install must be inspected, the listed 12 kW costs little more.
Amazon AIMS Power $4,160$4,160
Prices were last checked October 24, 2026 and are subject to change; the price and availability shown by the retailer at the time of purchase apply.
Which should you buy?
- Choose the AIMS Power 8000W 48V Split Phase ETL for safety listing (ETL listed to UL 1741 and CSA C22.2 No. 107.1 vs no UL 458 or UL 1741 listing stated), idle draw (100 W idle with nothing plugged in vs 150 W idle with nothing plugged in) and features (optional remote, app add-on, lithium charge profile, 120/240 V split-phase, hardwire terminal, display vs optional remote, app add-on, lithium charge profile, 120/240 V split-phase, hardwire terminal).
- Choose the AIMS Power 10000W 48V Split Phase for value ($0.42 per continuous watt vs $0.56 per continuous watt).
Scores side by side
Each factor is scored 0-100 against the same fixed reference points for every split-phase inverter-chargers 48V inverter; a clear win is highlighted. How we rank explains each one.
| Factor weight | AIMS Power 8000W 48V Split Phase ETL | AIMS Power 10000W 48V Split Phase |
|---|---|---|
| Overall rating | 3.1/5 | 2.7/5 |
| Value 30% | 0 $0.56 per continuous watt | 30 $0.42 per continuous watt |
| Idle draw 15% | 57 100 W idle with nothing plugged in | 29 150 W idle with nothing plugged in |
| Safety listing 15% | 100 ETL listed to UL 1741 and CSA C22.2 No. 107.1 | 0 no UL 458 or UL 1741 listing stated |
| Warranty 15% | 50 3-year warranty | 50 3-year warranty |
| Features 15% | 80 optional remote, app add-on, lithium charge profile, 120/240 V split-phase, hardwire terminal, display | 70 optional remote, app add-on, lithium charge profile, 120/240 V split-phase, hardwire terminal |
| Efficiency 10% | 33 88% peak efficiency (maker rating) | 33 88% peak efficiency (maker rating) |
Specifications
| AIMS Power 8000W 48V Split Phase ETL | AIMS Power 10000W 48V Split Phase | |
|---|---|---|
| Output | ||
| Type | Pure sine wave inverter-charger | Pure sine wave inverter-charger |
| AC output | 120/240 V split-phase | 120/240 V split-phase |
| Continuous power | 8,000 W | 10,000 W |
| Surge power | 24,000 W for 20 s | 30,000 W for 20 s |
| DC input range | 40 to 64 V | 40 to 64 V |
| Idle draw | 100 W (2.1 A at 48 V) | 150 W (3.1 A at 48 V) |
| Power-saving draw | 30 W | 35 W |
| Peak efficiency | 88% | 88% |
| Connections | ||
| AC outlets | 2 | 2 |
| GFCI outlets | No | No |
| Hardwire terminal | Yes | Yes |
| USB ports | None | None |
| Transfer switch | Yes | Yes |
| Pass-through rating | 50 A | 63 A |
| Charger | 80 A | 100 A |
| Lithium charge profile | Yes | Yes |
| Parallel units | No | No |
| Control and build | ||
| Remote | Optional extra | Optional extra |
| App | Optional add-on | Optional add-on |
| Display | Yes | No |
| Safety listing | ETL listed to UL 1741 and CSA C22.2 No. 107.1 | No |
| Design | Low-frequency (transformer) | Low-frequency (transformer) |
| Cooling | load-controlled fan | load-controlled fan |
| Dimensions | 23.3 x 16.3 x 7.9 in | 23.3 x 16.3 x 7.9 in |
| Weight | 132 lb | 145.5 lb |
| Warranty | 3 years | 3 years |
| Released | - | 2015-10 |
