Victron SmartSolar MPPT 150/85-Tr
#9 in MPPT solarFull review
For large 48 V off-grid or backup systems near 5 kW of panels on one controller. A solid pick when you also run a Victron GX device.
Amazon DRSA $476$476
4.2/5
For large 48 V cabin, RV or boat systems of around 4 kW of panels. Worth the premium if you want Victron’s app, BMS control and warranty.
- 70 ACharge current
- 12/24/36/48 VBattery
- 150 V maxPV input
- 98%Efficiency
- 5 yearsWarranty
Check price at AmazonCheck price at DRSA$402.05
Price checked October 24, 2026. As an Amazon Associate we earn from qualifying purchases.
Pros
- Runs about 4,000 W of panels on a 48 V bank
- 150 V input allows long series strings and thinner cable runs
- Remote on/off port and relay make it easy to tie into a lithium BMS
- Fanless, with a five-year warranty
Cons
- Costs more per amp than budget 70 A controllers
- No built-in screen without the optional display
- Battery temperature sensing is an extra purchase
The Victron SmartSolar MPPT family
Every Victron SmartSolar MPPT model we rank, smallest first. Ratings compare each against its own type.
| Model | Charge current | Rating | Price |
|---|---|---|---|
| Victron SmartSolar MPPT 75/15 | 15 A | 4.2/5 | $70.55 |
| Victron SmartSolar MPPT 100/20-48V | 20 A | 4.3/5 | $93.50 |
| Victron SmartSolar MPPT 100/30 | 30 A | 4.3/5 | $135.15 |
| Victron SmartSolar MPPT 150/35 | 35 A | 4.2/5 | $193.80 |
| Victron SmartSolar MPPT 150/45 | 45 A | 4.3/5 | $229.50 |
| Victron SmartSolar MPPT 100/50 | 50 A | 4.4/5 | $193.80 |
| Victron SmartSolar MPPT 150/60-Tr | 60 A | 4.1/5 | $368.90 |
| Victron SmartSolar MPPT 250/60-Tr | 60 A | 4.1/5 | $435.20 |
| Victron SmartSolar MPPT 150/70-Tr (this one) | 70 A | 4.2/5 | $402.05 |
How it scores
The rating comes from 4 measured or published factors, each scored 0-100 against fixed reference points for its type. How we rank explains each one.
Specifications
| Model number | SCC115070211 |
|---|---|
| Charging | |
| Type | MPPT solar charge controller |
| Charge current | 70 A |
| Battery voltage | 12/24/36/48 V |
| Lithium profile | Yes |
| Custom profile | Yes |
| Temperature sensor | Optional extra |
| Peak efficiency | 98% |
| Standby draw | 35 mA |
| Inputs | |
| Max PV voltage (Voc) | 150 V |
| Max PV power (12 V) | 1,000 W |
| Max PV power (48 V) | 4,000 W |
| Monitoring and build | |
| Bluetooth | Built in |
| Display | No |
| Load output | No |
| Parallel units | Yes |
| Cooling | passive (no fan) |
| Water resistance | IP43 (electronics), IP22 (connection area) |
| Dimensions | 185 x 250 x 95 mm |
| Weight | 6.6 lb |
| Warranty | 5 years |
