Victron SmartSolar MPPT 150/35
#8 in MPPT solarFull review
For mid-size 48 V cabin, van or backup systems up to about 2 kW of panels. A compact, efficient Victron at a fair price per amp.
Amazon DRSA $193.80$193.80
4.2/5
For big 48 V arrays wired in long high-voltage strings. Worth it over the 150/85 only if the 250 V input saves real cable cost.
- 85 ACharge current
- 12/24/36/48 VBattery
- 250 V maxPV input
- 99%Efficiency
- 5 yearsWarranty
Check price at AmazonCheck price at Inverters R Us$576.30
Price checked October 24, 2026. As an Amazon Associate we earn from qualifying purchases.
Pros
- Runs about 4,900 W of panels on a 48 V bank
- 250 V input takes long series strings, so distant arrays need thinner cable
- Remote on/off port, relay and VE.Can make it easy to tie into a lithium BMS and GX system
- Fanless, with a five-year warranty
Cons
- Costs more than the 150/85 for the same charge current
- Heavier and larger than the 70 A models
- Battery temperature sensing is an extra purchase
The Victron SmartSolar MPPT VE.Can family
Every Victron SmartSolar MPPT VE.Can model we rank, smallest first. Ratings compare each against its own type.
| Model | Charge current | Rating | Price |
|---|---|---|---|
| Victron SmartSolar MPPT 250/70-Tr | 70 A | 4.1/5 | $536.35 |
| Victron SmartSolar MPPT 150/85-Tr | 85 A | 4.2/5 | $476 |
| Victron SmartSolar MPPT 250/85-Tr (this one) | 85 A | 4.2/5 | $576.30 |
| Victron SmartSolar MPPT 150/100-Tr | 100 A | 4.3/5 | $542.30 |
| Victron SmartSolar MPPT 250/100-Tr | 100 A | 4.3/5 | $643.45 |
How it scores
The rating comes from 4 measured or published factors, each scored 0-100 against fixed reference points for its type. How we rank explains each one.
Specifications
| Model number | SCC125085411 |
|---|---|
| Charging | |
| Type | MPPT solar charge controller |
| Charge current | 85 A |
| Battery voltage | 12/24/36/48 V |
| Lithium profile | Yes |
| Custom profile | Yes |
| Temperature sensor | Optional extra |
| Peak efficiency | 99% |
| Standby draw | 35 mA |
| Inputs | |
| Max PV voltage (Voc) | 250 V |
| Max PV power (12 V) | 1,200 W |
| Max PV power (48 V) | 4,900 W |
| Monitoring and build | |
| Bluetooth | Built in |
| Display | No |
| Load output | No |
| Parallel units | Yes |
| Cooling | passive (no fan) |
| Water resistance | IP43 (electronics), IP22 (connection area) |
| Dimensions | 216 x 295 x 103 mm |
| Weight | 9.9 lb |
| Warranty | 5 years |
| Released | 2020-04 |
Alternatives in this type
Victron SmartSolar MPPT 150/85-Tr
#9 in MPPT solarFull review
For large 48 V off-grid or backup systems near 5 kW of panels on one controller. A solid pick when you also run a Victron GX device.
Amazon DRSA $476$476
Victron SmartSolar MPPT 150/70-Tr
#11 in MPPT solarFull review
For large 48 V cabin, RV or boat systems of around 4 kW of panels. Worth the premium if you want Victron’s app, BMS control and warranty.
Amazon DRSA $402.05$402.05
Compare
Compare the Victron SmartSolar MPPT 250/85-Tr with any other charge controller →
More from Victron Energy: every Victron Energy product ranked.
