Victron SmartSolar MPPT 150/45
#3 in MPPT solarFull review
For 48 V cabin and backup systems of around 2.5 kW of panels that want Victron’s app in a small case. Among the best value per amp in the SmartSolar range.
Amazon DRSA $229.50$229.50
4.3/5
For large 48 V off-grid homes with long or high-voltage strings that want 100 A from one controller. The top of Victron’s screw-terminal range.
- 100 ACharge current
- 12/24/36/48 VBattery
- 250 V maxPV input
- 99%Efficiency
- 5 yearsWarranty
Check price at AmazonCheck price at DRSA$643.45
Price checked October 24, 2026. As an Amazon Associate we earn from qualifying purchases.
Pros
- Handles about 5,800 W of panels on a 48 V bank
- 250 V input takes long series strings, so distant arrays need thinner cable
- Remote on/off port, relay and VE.Can make it easy to tie into a lithium BMS and GX system
- Fanless, with a five-year warranty
Cons
- Costs about $100 more than the 150/100 for the same charge current
- Heavier and larger than the 70 A models
- Battery temperature sensing is an extra purchase
The Victron SmartSolar MPPT VE.Can family
Every Victron SmartSolar MPPT VE.Can model we rank, smallest first. Ratings compare each against its own type.
| Model | Charge current | Rating | Price |
|---|---|---|---|
| Victron SmartSolar MPPT 250/70-Tr | 70 A | 4.1/5 | $536.35 |
| Victron SmartSolar MPPT 150/85-Tr | 85 A | 4.2/5 | $476 |
| Victron SmartSolar MPPT 250/85-Tr | 85 A | 4.2/5 | $576.30 |
| Victron SmartSolar MPPT 150/100-Tr | 100 A | 4.3/5 | $542.30 |
| Victron SmartSolar MPPT 250/100-Tr (this one) | 100 A | 4.3/5 | $643.45 |
How it scores
The rating comes from 4 measured or published factors, each scored 0-100 against fixed reference points for its type. How we rank explains each one.
Specifications
| Model number | SCC125110412 |
|---|---|
| Charging | |
| Type | MPPT solar charge controller |
| Charge current | 100 A |
| Battery voltage | 12/24/36/48 V |
| Lithium profile | Yes |
| Custom profile | Yes |
| Temperature sensor | Optional extra |
| Peak efficiency | 99% |
| Standby draw | 35 mA |
| Inputs | |
| Max PV voltage (Voc) | 250 V |
| Max PV power (12 V) | 1,450 W |
| Max PV power (48 V) | 5,800 W |
| Monitoring and build | |
| Bluetooth | Built in |
| Display | No |
| Load output | No |
| Parallel units | Yes |
| Cooling | passive (no fan) |
| Water resistance | IP43 (electronics), IP22 (connection area) |
| Dimensions | 216 x 295 x 103 mm |
| Weight | 9.9 lb |
| Warranty | 5 years |
| Released | 2020-04 |
Alternatives in this type
Victron SmartSolar MPPT 100/30
#4 in MPPT solarFull review
A strong default for 300-450 W van and RV arrays on 12 V. It is well priced for a five-year-warranty controller with a built-in app.
Amazon Expion360 $135.15$135.15
Victron SmartSolar MPPT 100/20-48V
#6 in MPPT solarFull review
For small 48 V systems with one or two strings of panels, such as a shed, pump or backup bank. A dependable, inexpensive Victron with the app and a five-year warranty.
Amazon $96.31 DRSA $93.50$93.50
Compare
Compare the Victron SmartSolar MPPT 250/100-Tr with any other charge controller →
More from Victron Energy: every Victron Energy product ranked.
