Mitsubishi Hyper-Heat FX 24,000 BTU
#1 in 24,000 BTUFull review
Mitsubishi’s flagship cold-climate system: it makes more than its rated heat at 5 °F and keeps heating to −22 °F. For a home that relies on it as the main heat through a cold winter.
4.5/5
Fujitsu’s cold-climate line, with more than its rated heat at 5 °F and very high certified efficiency, for homes heating through a cold winter.
- 24,000 BTUSize
- 25,800 Btu/hHeat at 5 °F
- 102%Kept at 5 °F
- 11.9 / 24HSPF2 / SEER2
- Pro installInstall
See it at Fujitsu
No store we check sells it online; the maker lists where to buy or who installs it.
Pros
- Makes 25,800 Btu/h at 5 °F, more than its rated 25,200 Btu/h
- 10-year parts and compressor warranty once registered
Cons
- Needs a licensed HVAC installer: a self-install voids the warranty
How it scores
The rating comes from 4 measured or published factors, each scored 0-100 against fixed reference points for its size. How we rank explains each one.
Specifications
| Capacity (certified) | |
|---|---|
| Size (nominal) | 24,000 BTU |
| Cooling at 95 °F | 22,000 Btu/h |
| Heating at 47 °F | 25,200 Btu/h |
| Heating at 17 °F (max) | 28,900 Btu/h |
| Heating at 5 °F (max) | 25,800 Btu/h |
| Heat kept at 5 °F | 102% |
| Efficiency (certified) | |
| HSPF2 (Region IV) | 11.9 |
| SEER2 | 24 |
| EER2 | 12.5 |
| COP at 5 °F | 2.06 |
| ENERGY STAR | ENERGY STAR Cold Climate |
| AHRI certificate | 215647924 |
| Operating range | |
| Heats down to | -15 °F |
| Cooling range | 14 to 122 °F |
| Installation | |
| Installed by | Professional (sold through installers) |
| Line set connection | Flare fittings (vacuum pump needed) |
| Line set | up to 164 ft |
| Voltage | 230 V |
| Refrigerant | R-32 |
| Indoor unit | ASUH24KZAS |
| Outdoor unit | AOUH24KZAH1 |
| Build | |
| Indoor noise | 30–47 dB(A) |
| Outdoor noise | 51 dB(A) |
| Wi-Fi | Built in |
| Weight | indoor 36 lb / outdoor 117 lb |
| Warranty | 10 yr compressor, 10 yr parts |
| Warranty with DIY install | No, a licensed installer is required |
